H.M.S. Moon Rocket

In the 1930s, Arthur C. Clarke and friends designed their own lunar mission.

Arthur C. Clarke (far right) and other members of the British Interplanetary Society had a visit from rocket pioneer Robert Truax (holding the rocket model) in 1938. National Air and Space Museum

In the summer of 1939, the members of the British Interplanetary Society may have been the only optimists left in Europe. Nazi Germany was steadily building up its military machine, and the continent appeared to be slipping inexorably toward another devastating conflict.

But the small band of English eccentrics that made up the BIS had their attention elsewhere. Their gaze was fixed on the coming age of space travel, and more specifically on the problem of sending a rocket to the moon. They had formed their organization in 1933—at about the time rocket societies were blooming in Germany, Russia, and the United States—dedicating themselves to “the stimulation of public interest in the possibility of interplanetary travel…and the conducting of practical research in connection with such problems.”

In fact science fiction writers like Edgar Rice Burroughs and H.G. Wells had already stimulated the British interest in space. But even though the BIS members were almost all science fiction fans, they cringed at the way space travel was portrayed in movies and popular books. Writing in the February 1937 issue of the society’s journal, D.W.F. Mayer, an associate member from Leeds, panned the film version of Wells’ Things to Come for having depicted astronauts being launched by a space gun. After calculating that the resulting force on a 120-pound person would equal 435 tons, he chided, “If the Man in the Street is to be introduced to the possibility of space travel via the medium of films—especially films with as much publicity as was given to Things to Come—it is up to the writers of them to make sure their facts are reasonably accurate…. Play the game, Mr. Wells!”

From 1937 to 1939, about a dozen armchair astronauts on the BIS “Technical Committee” played the game by carrying out the first detailed study of a manned lunar mission, from propulsion to payload to pressure suits. Rather than dream up an anti-gravity drive or some other staple of science fiction, they used only physical principles and technologies already in hand. Some of the ideas, like a propulsion system based on 2,000 solid rocket motors, would certainly not have worked, while others—aerobraking and a parachute descent to Earth, a three-man crew, and a focus on geological prospecting once the moon had been attained—proved amazingly prescient.

The BIS was not the first to consider the technical requirements of a lunar voyage. Rocket pioneers like Russian school teacher Konstantin Tsiolkovsky and German engineer Hermann Oberth had already done some thinking on the subject. The American rocket scientist Robert Goddard had been ridiculed in 1919 for suggesting that a rocket could be sent to the far side of the moon. But BIS members were the first to analyze a lunar trip in a systematic way and spell out possible technical, logistical, and physical challenges.

In 1937, having just moved its operations from Liverpool to London, the four-year-old society was looking for a project that would popularize the notion of interplanetary travel and at the same time “prove that we are a body which may be entrusted with a scientific task,” in the words of one BIS officer. They bypassed more conservative ideas, like building a rocket car or firing mail across the Atlantic, electing instead to design a two-week round trip to the lunar surface.

The choice of such an ambitious goal wasn’t entirely high-minded. Unlike their counterparts in the United States and Germany, BIS members were forbidden by Britain’s Explosives Act of 1875 from shooting off real rockets. Hands-on experimentation with live propellants was out.

The society was also broke. Its members were mostly teenagers and young men, and few had money for expensive equipment. “The research fund remains at microscopic proportions,” lamented one author in the society’s journal.

So a careful, detailed, and cheap design study seemed just the ticket. A committee made of the few members who had at least some engineering or science background began meeting one evening a week, usually in someone’s flat, to sketch out plans. Heading the Technical Committee was J. Happian (Jack) Edwards, the director of a small electronics firm. A brilliant but irascible Welshman, Edwards didn’t suffer fools gladly. “There are plenty of mad scientists, but Edwards is the only mad engineer I ever knew,” says science fiction writer Arthur C. Clarke, who was also a member of the committee.

The 20-year-old Clarke was the group’s astronomer. As a teenager on his family’s farm in Somerset he had filled sketchbooks with drawings of lunar craters seen through a homemade telescope, and by 1938 he claimed to own every science fiction magazine ever published. Even before achieving world fame for co-authoring 2001: A Space Odyssey and predicting the invention of the communications satellite, his friends had nicknamed him Ego.

The team included another electrical engineer, Harold Ross, and Viennese chemist Arthur Janser. Perhaps the most important member after Edwards was his childhood friend R.A. (Ralph) Smith. An artist and self-taught engineer, Smith was, like Edwards, a bit older than the rest of the BIS members, and married. His daytime job was designing the interiors of London hotels and cinemas, but he had drawn his first rocket ship at age 12, and spaceflight was his true passion. A stickler for accuracy, his paintings brought to life many of the society’s most important concepts from its earliest days until his death in the 1950s.

Smith’s son Ashtyn, who later moved to the States and worked on the Apollo program, remembers watching through the banister as a seven-year-old while the Technical Committee discussed “propellants and mass ratios and such” in his parents’ living room. “They were the most unusual bunch of people you could expect to run across,” he says. “Real visionaries.” Clarke recalls that interspersed with the technical conversation was “quite a bit of fun,” and that the group was never averse to sending out for fish and chips or adjourning to a pub.

First Moon Men (1947)

 Cash-strapped as it was, the committee decided nonetheless to try to build whatever few devices its meager experimental fund would allow. “We were in the position of someone who couldn’t afford a car, but had enough for the speedometer and the rear view mirror,” Clarke later wrote.

Edwards designed an inertial guidance system—an aluminum disk with ball bearings, gears, weights, and springs attached—for sensing the spaceship’s speed and position. The committee planned to test the device in the London underground but never got around to it. Another instrument—the coelostat—did get built, and actually worked. Because the spaceship would be spinning at one rotation every three and a half seconds, the astronauts would have difficulty seeing out the portholes to navigate. The solution was the coelostat, a periscope-like gizmo with two fixed mirrors and two spinning ones, which compensated for the ship’s motion so the stars appeared stationary.

During one memorable meeting in Smith’s suburban London home, Edwards orchestrated a demonstration of how the coelostat would work in principle, using, among other things, Smith’s shaving mirror and his wife’s compact. “Soon,” wrote a wry observer in the BIS bulletin, “the room was full of living statuary, standing in graceful and artistic poses, holding mirrors above their heads.” When “fatigue began to overtake the living statues, wobble set in,” and Mrs. Smith had to rescue the “stricken Interplanetarians” with a tray of tea and sandwiches.

By January 1939 the committee was ready to show off its design in the more sober pages of the society’s journal. The six-stage moon rocket weighed in at 1,000 tons and could deliver a one-ton payload, including three astronauts, to the lunar surface. Each stage, or “step,” was a honeycomb of hundreds of tubular solid rocket motors—2,250 altogether—bundled together like sticks of dynamite. The sixth and final step would lift the vehicle off the lunar surface for the return to Earth. This “cellular” design—Edwards’ idea—allowed the motors to be mass produced, which dramatically reduced the cost of the mission.

It was all very elegant. And totally impractical.

“Where we went wrong was in assuming we could use solids,” says Clarke. The committee was well aware of liquid fuels, which even then were favored by most rocketeers. In fact, an affiliated astronautical society in Manchester, led by 18-year-old Eric Burgess, was designing its own moon rocket using “petrol and liquid oxygen.” But, recalls Clarke, “we worked out that [the main vehicle] would have to burn X tons of [liquid] fuel per second, and no one could imagine pumps that could handle that.” The BIS designers never suspected that over on the continent, a well-funded German team led by Wernher von Braun was on the verge of solving that very problem.

Working out the details of the vehicle’s payload, which fell to committee member Maurice Hanson, presaged the hard decisions NASA engineers would face 30 years later. Every item had to be chosen for compactness and minimum weight. Air and water would be extracted from a single tank of liquid hydrogen peroxide. The lunar explorers would carry, among other things, charts and books printed on “specially light rice-paper,” indelible balsa wood pencils, two large handkerchiefs for each crew member, spacesuits made of “thin but tough” rubber or leather, flat shoes, dark goggles and sunburn lotion for working on the lunar surface, geological hammers, spades, a “fairly powerful” telescope and microscope for mineralogy, and a canvas tent to place over the ship to reduce heat loss.

Foods would be selected for high energy content: bread and butter, cheese, porridge, raisins, ham, honey, and salmon. Water would be the basis of all beverages, “chief amongst which will be cocoa, though a small amount of coffee might be necessary as a stimulant for navigators falling asleep over their interminable calculations.”

The astronauts would communicate with Earth via “flashes of light.” By modulating the intensity of the beam, wrote Hanson, “a running commentary by one of the astronauts on the exploration of the Moon, broadcast by the BBC, is not beyond the bounds of possibility.”

Some of this was a little farfetched for even the other committee members, who had their hands full figuring out how to soften the spacecraft’s impact on the moon, or just getting the damn coelostat to work properly. Time, money, and lack of manpower were chronic problems. A few members began to wonder whether the original prediction—that a mission could be launched in 15 years (always pending the timely arrival of £ 200,000, of course)—might have been a trifle too bold.

If the members were beginning to have doubts, outsiders already thought they were crazy. Leonard Carter, who joined the society in 1937 and still works in its London office, says that talking about moon travel before World War II “was regarded as a form of lunacy, and not a mild one at that. People would cross the road to avoid us.”

The BIS membership set out to convince skeptics that their mission was possible. “We must explain that we are not peculiar people who desire to go to the moon like children who cry for a new toy,” wrote President A.M. Low, who had helped develop radio-controlled guided missiles in World War I.

Society members gave frequent lectures and demonstrations, even showing off the coelostat at a science museum in Kensington. Clarke did his part to spread the faith, even though he was often rebuked by someone in the audience “for talking utter nonsense.” After the war, he and fellow member Val Cleaver spent an evening in an Oxford pub trying to convince C.S. Lewis and J.R.R. Tolkien of the rightness of their cause. Neither writer joined the society, though eventually George Bernard Shaw did, at the age of 91.

The BIS moonship design generated a small flurry of publicity for the society in 1939, with articles appearing in Time magazine and publications from as far away as India. An editorial in the journal boasted that “once we stole half the photo-news page of a national Sunday newspaper from Herr Hitler.”

But Hitler had the last laugh. In September 1939 he invaded Poland, Britain declared war on Germany, and the society disbanded virtually overnight, as those members who hadn’t already enlisted were called up to service. When the BIS reconvened after the war (R.A. Smith was instrumental in rounding up former members), its ranks were older, more seasoned, and more numerous. Wernher von Braun’s V-2 had proven that rockets were no longer schoolboy fantasies, and now no one smiled at the idea of space travel.

The post-war BIS turned to more practical near-term tasks, including holding a landmark conference in 1951 to plan the world’s first orbiting satellite. The society became, and remains today, an important incubator for advanced thinking about space technology, and its journal is one of the most respected in the field.

A few members of the original Technical Committee, mainly Smith and Ross, continued tinkering with the old moonship, publishing articles into the 1950s that refined the design. The postwar concepts were more sophisticated, at times coming close to what NASA actually launched a decade later.

Clarke went on to a celebrated career as a science fiction writer, and in July 1969 he sat at the right hand of Walter Cronkite as a commentator on the first moon landing. His friend Val Cleaver became chief engineer of Rolls-Royce’s rocket division. Burgess also became a successful writer and NASA consultant. Only Edwards seems to have peaked with his work on the BIS moonship. He drifted into alcoholism, moved to Ireland, and ended up choking to death on his false teeth.

R.A. Smith continued to collaborate with Clarke as an artist on several books and magazine articles, which earned him a small measure of fame. He painted, invented, played Chopin on the piano, and dreamed constantly of space travel. Several years before he died in 1959 at the age of 54, Smith quit the factory where he had been happily designing rocket powerplants and took a less rewarding job with a company that made pressure control devices. He didn’t want to work on missiles, so out of principle he resigned.

Meanwhile, in Huntsville, Alabama, Wernher von Braun, a dreamer of a more pragmatic bent, was already hatching his own plans for a giant rocket that could send people to the moon.

The final stage of the moon rocket was to settle on six landing legs (20), using steam steering jets (2) and spin control jets (4) to maneuver. Mission completed, the craft would blast off from the lunar surface propelled by a bundle of rockets (1) and jettison its heat shield after re-entry (9). National Air and Space Museum
The BIS spacesuit had the look of armor worn by Roman centurions, but every feature had a purpose: (1) an anti-glare peak on the helmet, (4) an antenna for radio communications, (6) an air pipeline, (9) "a roomy armhole to permit withdrawal of arm," (10) an air conditioning unit, (16-18) "pull-on" boots with articulated and spiked metal soles and inner thermal insulating soles, and, most dashingly, (22) "silvered cape (used to regulate temperature at night)." National Air and Space Museum
